Multiple Redwood Viscometer Apparatus

38500 INR/Piece

Get a Price/Quote

Product Details:

Power Source Electric
Feature Simultaneous multiple sample testing
Frequency 50 Hz
Automation Grade Manual
Product Type Redwood Viscometer Apparatus
Voltage 220V AC
Temperature Range Ambient to 100C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Multiple Redwood Viscometer Apparatus Price And Quantity

Minimum Order Quantity 1 Piece
Price 38500 INR/Piece

Multiple Redwood Viscometer Apparatus Product Specifications

Measurement Range Viscosity as per Redwood 1 & 2 methods
Capacity Multiple cup arrangement
Frequency 50 Hz
Product Type Redwood Viscometer Apparatus
Automation Grade Manual
Equipment Materials Mild Steel
Usage For Laboratory Use
Temperature Range Ambient to 100C
Display Type Analog
Voltage 220V AC
Core Components Oil Cups, Bath, Heater, Thermometer, Stopwatch
Weight Approx. 25 kg
Material Mild Steel
Power Source Electric
Accuracy 0.5% FSD
Model No MRV-04
Type Redwood Viscometer Apparatus
Dimension (L*W*H) 650 mm x 300 mm x 500 mm
Color Grey
Feature Simultaneous multiple sample testing

Multiple Redwood Viscometer Apparatus Trade Information

Payment Terms Cash in Advance (CID), Cash Advance (CA)
Supply Ability 1 Piece Per Day
Delivery Time 2-3 Days
Main Export Market(s) Western Europe, Middle East, Central America, Eastern Europe, South America, Asia, North America, Australia, Africa
Main Domestic Market All India

Product Description

With firm commitment to quality, we are involved in manufacturing, exporting and supplying the wide range of Multiple Redwood Viscometer Apparatus. This apparatus is majorly used to determine the viscosity of fluids. Offered apparatus is efficiently manufactured under the strict guidance of specialized professionals by make utilization of excellent quality components and the latest techniques. Further, this Multiple Redwood Viscometer Apparatus can avail from us in several specifications as per the varied needs of the clients.

Features:

High functionality
Easy maintenance
Hassle-free operation
Excellent performance

Technical Description-

Made of stainless steel bath big enough to accomodate 3 cups Redwood No.1 and 2 cups of Redwood No.II. Stirring is done by a FHP electric motor in the bath. It is supplied complete with 5 Oil cups fitted with Precision jets of Stainless Steel. Temperature is controlled by Energy Regulator

Optinal Accessories For Red Wood Viscometer No. I,II & Multiple Red Wood Viscometer:

8'C Low range Thermometer.
9'C Medium range Thermometer.
10'C High range Thermometer.
Flask receiver 50 ml capacity.
Polished carrying wooden case for Red wood No.I.
Temperature regulator (Energy regulator).
Spare cup with valve for Redwood No.I.
Spare cup with valve for Redwood No.II.
Polished carrying wooden case for Redwood No.II.
Spare Heater for Red Wood No.I.
Spare Heater for Red Wood No.II.
Spare Ball valve for Red Wood No.I & II.
Digital temperature controller cum indicator for Red Wood No I & II.

Advanced Technocracy Inc. is Manufacturer, Exporter, Trader & Supplier of Multiple Redwood Viscometer Apparatus

Simultaneous Multi-Sample Testing

This viscometer features four independent oil cups, allowing you to conduct up to four viscosity tests at the same time. Each cup is equipped with a dedicated drain valve for effortless sample handling and cleaning. This design significantly increases productivity and allows quick, direct comparisons between multiple oil samples under identical test conditions.

Precision and Compliance Assured

Equipped with a 0-100C analog thermometer and accurate temperature control (0.5% FSD), the apparatus ensures reliable readings. Overtemperature protection safeguards both user and sample integrity. The equipment strictly follows IS 1448 and ASTM protocols, ensuring that your results meet national and international laboratory standards for viscosity determination.

Durable Construction for Long-Term Use

Manufactured from high-quality mild steel with a corrosion-resistant, powder-coated grey finish, this viscometer is built for daily laboratory usage. The design integrates a heavy-duty tripod stand for stability, supporting rigorous testing environments. Components are chosen for durability, making this a dependable choice for repeated use in industrial or research settings.

FAQ's of Multiple Redwood Viscometer Apparatus:

Q: How does the Multiple Redwood Viscometer Apparatus operate?

A: The apparatus measures the viscosity of oils by timing how long a fixed sample (50 ml) takes to flow through a standardized orifice at controlled temperatures. Each oil cup is individually filled, and the bath medium (water or oil) is heated using the 500 W heater. Viscosity is determined according to established Redwood 1 & 2 protocols.

Q: What are the main benefits of using a multi-cup viscometer in the laboratory?

A: Utilizing a multiple cup arrangement enables simultaneous analysis of four samples, saving time and enhancing efficiency. This capability allows direct performance comparison across samples under uniform conditions, streamlining quality control and research processes.

Q: When should I use water versus oil as the bath medium?

A: Use water as the bath medium for testing at temperatures up to 100C. For tests requiring elevated or more stable temperatures, oil is recommended due to its higher boiling point and stable thermal properties. Both options provide a controlled environment for accurate viscosity measurement.

Q: Where is the overtemperature protection feature applied in this apparatus?

A: Overtemperature protection is integrated into the heating system to automatically prevent the bath from exceeding set limits, ensuring the safety of both the operator and the integrity of oil samples during extended or high-temperature testing.

Q: What process is followed for cleaning and draining the oil cups after use?

A: Each oil cup features its own drain valve, allowing for precise and easy removal of used oil after testing. Once drained, cups can be cleaned with appropriate solvents, ensuring the apparatus remains free of residue for accurate future tests.

Q: Is the Multiple Redwood Viscometer suitable for compliance testing as per IS 1448 and ASTM standards?

A: Yes, this model complies with IS 1448 and ASTM requirements, making it suitable for regulatory and standardized laboratory assessments in industries such as lubricants, petroleum, and quality control.
