Slit Lamp

Product Description

For many years, we are committed to manufacture, export and supply an excellent quality Slit Lamp. It consists of a high-intensity light source that focused to shine a thin sheet of light into the eye. The provided lamp is used in conjunction with a biomicroscope. This lamp is extensively used for the examination of the posterior segment and anterior segment of the human eye such as eyelid, natural crystalline lens, sclera, conjunctiva, iris and cornea. Our offered lamp is duly examined under the vigilance of our quality experts to ensure its long service life. Moreover, we provide this Slit Lamp in numerous models and technical specifications at market leading prices.

Features:

Type: Stereoscopic Microscope

Eye Pieces:                             10x

Objective:                               1x, 1.6x

Total Magnification:                  10x, 16x

Diameter of Visual Field:            18 mm, 14.5 mm, 9 mm

ILLUMINATION-

Slit Projection Magnification:      2/3 x

Slit Width:                              Continuous from 12 mm to 0 mm (at 10 mm slit becomes a circle)

Slit Length:                             Continuous from 12 mm to 1 mm Or Aperture settings at 9,8,5,3,2,1 and 0.2 mm dia.

Slit Angle:                              0 deg. to 180 deg. with horizontal Scanning capability

Slit Inclination:                       0, 5 deg., 10 deg., 15 deg. and 20 deg. steps.

Filters:                                  Blue, Red Free, ND, Heat-Absorbing No Filter

BASE-

Longitudinal Movement:            95 mm

Lateral Movement:                  105 mm

Fine Base Movement:               15 mm (with joystick)

Vertical Movement:                  32 mm

CHIN REST-

Vertical Movement:                  82 mm

Fixation Target:                       Luminous Target

Red LED POWER

Input (primary):                       AC 220V / 110V

Frequency:                             50 / 60 Hz

Output (secondary):                 Main Bulb 2.4v, 6.0v for Brightness levels

Power Consumption:                 26V A

DIMENSIONS & WEIGHT-

Table Model:                           560 x 407 mm

Unit Model:                             375 x 335 mm

Weight:                                  21 kg

STANDARD ACCESSORIES-

Dust Cover, Replacing Lamp for illumination unit

Versatile Magnification and Field of View

Benefit from five distinct magnification levels (6x-40x) and widefield eyepiece options for crystal-clear visualization. The 14-22 mm field of view and high-resolution optics ensure detailed examination of ocular structures.


Advanced Illumination and Filtering

The slit lamp utilizes high-efficiency LED illumination with adjustable brightness, providing consistent lighting for precise diagnosis. Integrated cobalt blue, red-free, and neutral density filters support various clinical procedures.


Precision Movement and Adjustment

Designed with an ergonomic joystick-driven mechanical system for smooth X-Y-Z axis movement, along with easy manual chinrest adjustment and interpupillary settings (52-78 mm), this device delivers user-friendly operation and accurate patient alignment.


Sturdy, Safe, and Efficient

Constructed from robust aluminum and optical glass, this medical-grade slit lamp is durable and reliable. It is intended for easy surface disinfection and consumes just 40-60W of power, ensuring safety and efficiency in clinical environments.
